Seawater Products
SWER: 39600-316800 GPD
Reverse Osmosis Seawater Systems
Ruggedized
Energy Recovery
PLC Operation
1200 PSI
Fully Systemized Prefiltration + Post Treatment
SWER systems are ruggedized Seawater systems fully integrated with prefiltration and post treatment of the potable water output. They are ideal for harsh environments such as seen in the oil industry, military environments and for water with challenging contaminants and high salinity. They are also ideal where a turnkey system is desired with automation of all the components from one central location.
The systems include heavy duty steel frames with vibration isolation and energy recovery with variable frequency drives. The pressure vessel and membranes are rated to 1200 psi making the systems fully useable in high salinity applications. A Siemens PLC with a color touch screen is used on the SWER, integrating full prefiltration of the seawater, and post treatment of the permeate, all controlled from one screen.
The systems come standard skid mounted but are available modular and constructed inside ISO containers.
| MODEL # | GPD | TPD | LPH | GPM | Feed Flow GPM |
Membranes (8" Diameter) |
HP Pump |
System Power (kW) |
|---|---|---|---|---|---|---|---|---|
| SWER39K | 39,600 | 150 | 6,203 | 27.5 | 67 | 12 | 40 | 50 |
| SWER52K | 52,800 | 200 | 8,333 | 36.7 | 88 | 18 | 75 | 60 |
| SWER79K | 79,200 | 300 | 12,407 | 55.0 | 132 | 18 | 100 | 60 |
| SWER105K | 105,600 | 400 | 16,543 | 73.3 | 176 | 24 | 100 | 70 |
| SWER132K | 132,000 | 500 | 20,833 | 91.7 | 223 | 36 | 125 | 100 |
| SWER158K | 158,400 | 600 | 24,816 | 110.0 | 264 | 42 | 150 | 120 |
| SWER211K | 211,200 | 800 | 33,088 | 146.7 | 352 | 48 | 200 | 178 |
| SWER264K | 264,000 | 1,000 | 41,660 | 183.3 | 447 | 60 | 200 | 178 |
| SWER316K | 316,800 | 1,200 | 49,632 | 219.4 | 528 | 72 | 250 | 200 |
